Z Axis
Z axis design and build of the first prototype version is now completed ! As expected, the Z axis has a NEMA 17 400 steps, a ball screw 1204 with coupler, a linear axis for movement, an anti wobbling coupler and a top mount with end stop ! The complete axis is independent and can…
Z anti wobble coupler
the Z axis is based on a MGN12 linear rail and and SFU 1204. both of these parts are extremely stiff and the cheap version of the SFU1204 are note exactly straight. The movement of the SFU1204 with a fix mount to the rail will generate bendings and torsion of the frame and generate Z…
Z Axis Top Mount
This is the first design of the Z Axis top mount. The parts join together the Linear Axis and the ball screw. It also includes an optical end stop and a mount on a 2020 profile. the part is available on the Gitlab repository under the Z Axis directory ( version 24 )
Alpha : the frame
Each project has to start somewhere… In the case of Alpha, the frame is the start ! The initial prototype frame is based on a 2020 and 2040 aluminum frame. This frame is big enough to mount everything the printer will need to be able to print a volume of 400x400x450 mm . The frame…
Alpha development started
The development of the Far Out Alpha printer as started. The Alpha is a professional desktop FDM printer.
Two Trees Saphire Pro Review
I received the Two Tress Sapphire Pro from a friend who has been using it for a while and decided to move on to something more compact. He gave me the printer mentioning that the extruder was no longer working. Operations The printer make a first good impression, it is a core XY system with…
DaVinci 1.0 Pro Review
The DaVinci 1.0 Pro is a really good looking printer for the price tag. The specification shows ABS, PLA, PETG and wood to be printed with some interesting accuracy. One of my neighbor was selling a bright new one he won in a waffle and I got it for a good price, could not say…
pyCalibration V1.1.0
Version 1.1.0 has been released ! The release includes more testing, better code stability and improve performances. For more information read the docs at http://pycalibration.readthedocs.io/. pyCalibration is available at pypi.org and can be installed directly with pip. The development code is hosted on gitlab at https://gitlab.com/far-out/eeshei5hopah.git, the documentation can be generated locally from the source…
